| General Info | Product Series | Parker D1FV Series (Proportional Pressure Reducing Valve) |
| Full Part Number | D1FVE02CC0NJW310 | |
| Size & Mounting | Nominal Size | NG06 (ISO 4401-03 / CETOP 03 / NFPA D03) |
| Mounting Pattern | Subplate mounting (requires NG06 interface) | |
| Hydraulic Performance | Valve Type | Direct-operated proportional pressure reducing valve |
| Spool Type | E02 (3-position, 4-way, spring-centered, all ports blocked in center position) | |
| Pressure Range | 25 Bar (363 PSI) | |
| Max. Flow | 8 L/min (at Δp = 10 bar per metering edge) | |
| Max. Operating Pressure | 350 bar | |
| Electrical Characteristics | Control Type | Integrated Digital On-Board Electronics (OBE) |
| Supply Voltage | 24 VDC (18…30 VDC, ripple < 5% rms, no surge) | |
| Command Signal | 0 to +10 V (Analog voltage input) | |
| Current Consumption | Max. 2 A; Pre-fuse: 2.5 A | |
| Electrical Connector | Deutsch DT04-2P (2-pin connector) | |
| Cable Specification | 3 x 1.5 mm² (AWG16), overall braided shield, max. length 50 m (164 ft) | |
| Material & Environment | Seal Material | NBR (Nitrile Rubber) |
| Operating Temperature | -20°C to +60°C (Coil temp. may reach 150°C / 302°F) | |
| Duty Cycle | 100% ED | |
| Protection Class | IP65 per EN 60529 (when mated and installed) | |
| Fluid Type | Hydraulic oil per DIN 51524 | |
| Special Features | Control Principle | Pressure feedback (closed-loop pressure control in ports A or B) |
| Hysteresis | Low hysteresis for high repeatability | |
| Manual Override | Standard | |
| Weight | 2.2 kg (4.9 lbs) |
D1FVE02CC0NJW3 Parker Proportional Valve
- About the Pressure Range (Code C): The
Cin the part number indicates a maximum regulated pressure of 25 Bar (363 PSI). This valve is designed for low-pressure control applications such as clamping, counterbalance, or pilot pressure regulation. - About the Spool (Code E02): The
E02spool type features a 3-position, 4-way, spring-centered design with all ports blocked in the center position. This allows for pressure control in either port A or port B depending on the command signal polarity. - About the Command Signal (Code W): The
Win the part number indicates a 0 to +10 V analog voltage input command signal. This is a standard industrial control signal compatible with most PLCs and motion controllers. - About the Connector (Code 310): The
310suffix indicates a Deutsch DT04-2P connector type. This is a rugged, environmentally sealed connector suitable for harsh industrial environments. - About the Seals (Code N): This valve uses NBR (Nitrile) seals, which are suitable for standard mineral-based hydraulic oils. If your system uses fire-resistant fluids or operates at high temperatures, you would need a valve with FKM (Viton) seals.
Original price was: $1,555.00.$886.00Current price is: $886.00.
