MOOG D664Z5703 L05HRBW6NVT0-Q Proportional Valve In stock

Applications and Precautions

Applications: The Moog D635-651 direct-drive proportional valve is specifically integrated with pressure-control (P-control) or p/Q limit functions, making it a critical component in electrohydraulic systems where precision force, clamping tension, or pilot system pressures must be continuously modulated. It is extensively applied in advanced plastic injection molding machines (for clamping and hold-pressure phases), specialized metal hydroforming presses, precise die-casting machinery, hydraulic test benches, and secondary pilot-stage pressure control loops in heavy automation.

Precautions:

Contamination Control: Given its role in high-precision closed-loop pressure loops, strict compliance with ISO 4406 < 14/11 fluid cleanliness is critical. A high-pressure, non-bypass filter must be positioned directly upstream.

Proper System Flushing: Never run contaminated fluid through the valve during initial commissioning. The entire hydraulic circuit must be thoroughly pre-cleaned via a dedicated flushing plate.

Stable Voltage Supply: Protect the integrated SMD electronics by ensuring a stable 24 VDC supply and installing an external 1.6 A slow-blow fuse to clear unexpected voltage spikes.

Parameter	Specification Details
Valve Series	D664 Series (2-Stage Servo-Proportional Valve)
Mounting Pattern	ISO 4401-05-05-0-94 (Size 05 / NG10)
Rated Flow ( $Q_n$ )	100 L/min to 130 L/min (at $\Delta p_N = 35$ bar per land)
Max Operating Pressure	350 bar (5,000 psi) at ports P, A, and B
Pilot Valve Type	ServoJet® (Superior dynamic response and debris tolerance)
Response Time ( $T_{90}$ )	Approx. 15 – 25 ms (highly dependent on pilot pressure)
Supply Voltage	24 VDC (18 to 32 VDC)
Command Signal	$\pm$ 10 V or 4-20 mA (Determined by specific electronic configuration)
Maximum Flow Rate	Up to 200 L/min (under maximum pressure drop conditions)
Degree of Protection	IP 65 (with properly mounted mating connector)
Hysteresis	< 0.5%
Seal Material	FKM (Viton) or NBR (Buna-N)

Warranty&Reture Policy:

1、One year warranty. If the product malfunctioned under proper usage per instructions manual within the warranty period, please contact us to obtain shipping instructions and send it back at your shipping costs.

2、14days evaluation and investigation takes placed after receiving yourreturn item.
