Valve for hydraulic REF. MOOG D661-6460C G35HOAA4VSX2HA Two-year warranty

Applications and Precautions

Applications: The Moog D661-6460C pilot-operated servo-proportional valve is custom-built for high-power electrohydraulic closed-loop systems requiring superior dynamic response, massive flow rates, and precise control over position, velocity, force, or pressure. Driven by its highly responsive ServoJet pilot stage, it is a critical component in demanding industrial machinery. Key applications include heavy plastic injection and blow molding equipment, die casting machinery, high-tonnage metal forming presses, steel mill hydraulic positioners, and aerospace/automotive test rigs.

Precautions:

Pilot Oil Cleanliness: The precision orifices of the ServoJet pilot stage are extremely sensitive to microscopic particles. A high-pressure, non-bypass filter fitted with a continuous clogging alarm must be installed directly upstream.

External Drain (Y Port): To secure optimal dynamic behavior and prevent backpressure fluctuations from disrupting the main stage, utilizing an external pilot drain connection (Port Y) is highly recommended.

Flushing Protocols: Never route initial system fluid through the valve; the complete hydraulic circuit must be aggressively flushed with a temporary flushing plate prior to final installation.

Parameter (参数项)	Specification & Value (指标与数据)
Valve Design (阀体设计)	2-Stage Pilot Operated Valve with integrated electronics and Electronic Feedback (EFB)
Pilot Valve Type (先导阀类型)	Robust ServoJet® pilot stage (or high-dynamic nozzle-flapper)
Mounting Pattern (安装界面)	ISO 4401-05-05-0-94 (Size 05 / NG10)
Maximum Operating Pressure (最大工作压力)	Ports P, A, B: 350 bar (5,000 psi) Port T (with internal Y): 210 bar (3,000 psi) Port T (with external Y): 350 bar (5,000 psi)
Rated Flow Range (系列额定流量范围)	20 to 200 l/min (5.3 to 52.8 gpm) @ $\Delta p_N$ = 35 bar per land
Maximum Flow (最大流量)	250 l/min (66 gpm)
Step Response Time (阶跃响应时间)	6.5 to 18 ms (highly dynamic for 0 to 100% stroke)
Supply Voltage (电源电压)	24 VDC (18 to 32 VDC)
Signal Command Options (控制信号)	$\pm$ 10 VDC / $\pm$ 10 mA / 4–20 mA (Typically configured for analog signals)
Spool Position Feedback (阀芯位置反馈)	4 to 20 mA actual value output (Pin F) for closed-loop diagnostic tracking
Hysteresis & Resolution (滞环与分辨率)	Hysteresis: < 0.2% / Resolution: < 0.1%
Degree of Protection (防护等级)	IP65 (with mating 6+PE pole connector properly mounted)
Fluid Temperature Range (介质温度范围)	-20 to +80 °C (-4 to +176 °F)
Recommended Cleanliness Class (推荐清洁度)	ISO 4406 < 14/11 (For longer wear life) / ISO 4406 < 16/13 (Normal operation)
